TotalPacks rotary pouch filling and sealing machine is designed for a wide range of pre-made pouches such as stand-up, zipper, or spout bags. It automatically completes pouch pick-up, opening, filling, sealing, and discharging in one compact rotary system.
The machine supports for various filling products including liquids, powders, granules, or pastes.
Optional functions include nitrogen flush, vacuum, multi-filling stations, spout pouch (corner or center) and zip-lock pouch applications.
Reliable performance, easy changeovers, and a hygienic stainless-steel structure make the machine ideal for the food, cosmetics, and chemical packaging industries.
For sales inquiries please contact us via email sales@totalpacks.com or click the button below
Features
Support bag width from 80 mm up to 240 mm to work with automatic pick up bags, coding batch code, opening bag, material filling, bag sealing and output.
Option: Nitrogen Flush, Vacuum, Multi-Filling, Spout Pouch (Conner or Center), Zip Pouch
8 work stations: 1) bag picking; 2) coding; 3) zip unit; 4) bag opening; 5) according to the material; 6) according to the material; 7) sealing and closing zip; 8) tidy to output;
Automatic Pre-made Pouch Rotary Packing Machine designed by Korea
Equipped with a 10” PLC touch screen with a graphic interface and an automatic lubricating system.
Washing down the frame, parts above the table made by 304# stainless steel and alumina material.
The whole machine weighs 1.8 tons, and its grippers can work at the 5 KGS bag loading.
Options for 6, 8, 10 workstations; also with vacuum rotary packaging machine with the rotary vacuum chamber.
Verify weight in weighing station, and compensate by servo filling system.
Vacuum pouch in sealing position
Spout at the center of the pouch
• Bag Size Range: Supports pouch widths from 80 mm to 240 mm, automatically completing bag pick-up, date coding, opening, filling, sealing, and discharge.
• Versatile Options: Compatible with nitrogen flush, vacuum, multi-filling, spout pouches (corner or center), and zip-lock pouches.
• Workstations: 8-station rotary design —
-bag pick-up;
-date coding;
-zipper opening unit;
-pouch opening;
-product filling (liquid, paste, powder, or granule);
-sealing and zipper closing;
-discharge and output arrangement.
• Engineering & Build: Automatic premade pouch rotary packing machine designed, equipped with a 10” PLC touch screen and automatic lubrication system for smooth operation.
• Construction: Washdown-grade frame; all parts above the table are made of SUS304 or SUS316 stainless steel and anodized aluminum, ensuring durability and hygiene.
• Performance: Machine weight approx. 1.8 tons, grippers rated for up to 5 kg pouch loading.
• Configurations: Available in 6-, 8-, or 10-station versions, as well as rotary vacuum models with vacuum chambers.
• Precision Filling: Integrated weighing station with servo-compensation for high filling accuracy.
• Vacuum Sealing: Supports vacuum pouch sealing and center spout pouch applications.
